Display and Control Your Android Device with OmniEdge

Scrcpy (pronounced "screen copy") is an application that provides display and control of Android devices connected via USB or TCP/IP. It does not require root access and works on GNU/Linux, Windows, and macOS.

With OmniEdge, Scrcpy can display and control Android devices over OmniEdge's peer-to-peer network from anywhere in the world.

Scrcpy Features

• Screen mirroring and recording
• Mirroring with device screen off
• Copy-paste in both directions
• Configurable quality
• Device screen as webcam (V4L2, Linux-only)
• Physical keyboard/mouse simulation (HID, Linux-only)

Requirements

• Android device with API 21+ (Android 5.0+)
• ADB debugging enabled on your Android device
• Additional option for keyboard/mouse control on some devices
• OmniEdge installed on your computer (macOS, Windows, Linux)

Note: OmniEdge for Android v2.x is coming soon. Currently, Android devices can be controlled via ADB over OmniEdge when connected to a computer running OmniEdge.

Install Scrcpy

macOS

brew install scrcpy

# Install ADB if not present
brew install android-platform-tools

Linux

# Ubuntu/Debian
sudo apt install scrcpy

# Or via snap
sudo snap install scrcpy

Windows

Download from Scrcpy Releases

Install OmniEdge

Quick Install (Linux/macOS)

curl -fsSL https://raw.githubusercontent.com/omniedgeio/omniedge/main/scripts/omniedge-install.sh | bash

Connect to Your Network

# Start OmniEdge (interactive login on first run)
sudo omniedge start

# Or use security key for automation
sudo omniedge start -s YOUR_SECURITY_KEY -n YOUR_NETWORK_ID

Verify Connection

omniedge status
# Note your virtual IP, e.g., 10.100.100.1

Connect Android Device via ADB

Option 1: USB First, Then Wireless

1. Connect Android device via USB
2. Enable ADB over TCP/IP:

adb tcpip 5555

3. Connect to the device's OmniEdge IP:

adb connect 10.100.100.2:5555

4. Disconnect USB cable

Option 2: Wireless ADB (Android 11+)

On Android 11+, you can pair wirelessly:

1. Go to Settings → Developer options → Wireless debugging
2. Tap Pair device with pairing code
3. On your computer:

adb pair 10.100.100.2:XXXXX  # Use the port shown on device
# Enter the pairing code

adb connect 10.100.100.2:5555

Display and Control Android with Scrcpy

Once ADB is connected over OmniEdge:

scrcpy --tcpip=10.100.100.2:5555

Example output:

scrcpy 2.4 <https://github.com/Genymobile/scrcpy>
INFO: Connected to 10.100.100.2:5555
INFO: Device: Samsung SM-G998B (Android 13)
INFO: Renderer: metal
INFO: Initial texture: 1080x2400

A window opens showing your Android device's screen, which you can control with your keyboard and mouse.

Advanced Scrcpy Options

# Lower quality for slower networks
scrcpy --tcpip=10.100.100.2:5555 --max-size 1024 --bit-rate 2M

# Record session
scrcpy --tcpip=10.100.100.2:5555 --record session.mp4

# View only (no control)
scrcpy --tcpip=10.100.100.2:5555 --no-control

# Stay awake while connected
scrcpy --tcpip=10.100.100.2:5555 --stay-awake

Use Cases

Remote Tech Support

Control a family member's Android device to help them troubleshoot:

1. Both devices connect to same OmniEdge network
2. ADB connect to their device's virtual IP
3. Use scrcpy to see and control their screen

Development and Testing

Test your Android app on a device at home while working remotely:

1. Leave Android device connected to a computer at home
2. Both computers join the same OmniEdge network
3. ADB connect and use scrcpy from anywhere

Digital Signage Management

Manage Android-based digital signage displays remotely:

1. Each display joins the OmniEdge network
2. Connect via ADB and scrcpy for management

If you have more questions, feel free to discuss.
